PFERD Angle handpieces WHA 10 90˚ G28

Angle handpiece WHA 10 90° G28 with 6 mm collet max. RPM 17,100

Collet group: 6

Dia. Externa: l67 mm

Handpiece-side coupling: G28

Handpiece-side coupling dia. [mm]: 28

Height: 67 mm

Incl. dia collet [mm] 6

Length: 165 mm

Net weight: 0.64 kg

PFERD typeWHA 10 90° G28

RPM, max: 17100 RPM

Transmission ratio: 1:1

Width: 38 mm

Packaging unit: 1 piece

Description

Angle handpiece 90° design with 6 mm collet and G28/diameter 28 mm sliding coupling, suitable for BW 10 SE 11 DIN 10/G28, BW 10 SE 11 DIN 10/G28 2m, BW 10 SE 11 DIN 15/G28, BW 10 SE 11 DIN 10/G28 oHA, BW 10 SE 11 DIN 10/G28 oHA 2m, and BW 10 SE 11 DIN 15/G28 oHA.

Contents

1 each of the following keys: EM SW 11 mm, EM SW 14 mm, and EM SW 14 mm, 1 collet.
