PFERD BW 12 DIN15/G28 oHA - Complete

Flexible shaft BW 12 DIN15/G28 without handpiece 12,000-850 RPM

Dia. drive-side coupling [mm]: 40

Dia. External: 25 mm

Drive-side coupling: DIN15

Handpiece-side coupling: G28

Handpiece-side coupling dia. [mm]: 28

Height: 25 mm

Length: 2112 mm

Net weight: 3.8 kg

PFERD type: BW 12 DIN 15/G28 oHA

RPM from: 850 RPM

RPM to: 12000 RPM

Version: Flexible shaft system 12

Width: 25 mm

Packaging unit: 1 piece

Description

Flexible shafts consist of three components which can be combined in different ways: the flexible core (SE), the flexible casing (SCH), the handpiece (HA).

The flexible core consists of four to ten layers of wire, conforming to DIN 2076, and is specially designed for high-speed clockwise rotation. The coupling is securely press-fitted to the core. After approximately 100 operating hours, the core of the flexible shaft must be re-lubricated. The flexible casing consists of oil-resistant rubber; the interior being a flat steel spiral and the outside being solid rubber. The connection couplings are pressed on firmly and encased in a rubber sheath as reinforcement. Because of low noise emissions, continuous operation with little fatigue is possible. Exchangeable collets enable a wide range of tools to be mounted. The sliding coupling enables quick handpiece changes.

Flexible shaft without handpiece.

Recommendations for use

It is essential that the rotational speed and power output do not fall below or exceed the specified ranges.

It is not possible to repair cores and flexible casings. We recommend replacement with pre-assembled new parts.
