PFERD Casing SCH 10 DIN10/G28 2M

Dia. drive-side coupling [mm]: 30

Dia. External: 22 mm

Drive-side coupling: DIN10

Handpiece-side coupling: G28

Handpiece-side coupling dia.[mm]: 28

Height: 22 mm

Length: 2053 mm

Net weight: 1.58 kg

PFERD type: SCH 10 DIN10/G28 2M

Version: Flexible shaft system 10

Width: 22 mm

Packaging unit: 1 piece

Description

Flexible shafts consist of three components, which can be combined in different ways: the flexible core (SE), the flexible casing (SCH), and the handpiece (HA).

The flexible core consists of four to ten layers of wire, conforming to DIN 2076, and is specially designed for high-speed clockwise rotation. The coupling is securely press-fitted to the core. After approximately 100 operating hours, the core of the flexible shaft must be re-lubricated. The flexible casing consists of oil-resistant rubber, with the interior being a flat steel spiral and the outside being solid rubber. The connection couplings are pressed on firmly and encased in a rubber sheath as reinforcement. Because of low noise emissions, continuous operation with little fatigue is possible. Exchangeable collets enable a wide range of tools to be mounted. The sliding coupling enables quick handpiece changes.

Replacement protective hose for BW 10 DIN 10/G28 2m and BW 10 DIN 10/G28 2m oHA.

Recommendations for use

It is essential that the rotational speed and power output do not fall below or exceed the specified ranges.

It is not possible to repair cores and flexible casings. We recommend replacing them with pre-assembled new parts.

When using flexible shafts, please ensure that the shafts are not bent beyond the specified radius of curvature. The smallest possible radius of curvature is given for each flexible shaft.

Ordering notes

Special lengths available on request.

Cores and hoses with double-sided sliding coupling on request.
